PROJECT 02 · EMBEDDED SYSTEMS
Dual-AxisSolar Tracker
A two-axis embedded control prototype that uses four light-dependent resistors and two servo motors to orient a panel toward the strongest light source.
- ACADEMIC CONTEXT
- EEEN 102 Embedded Systems Programming Final Project
- INSTITUTION / TEAM
- Istanbul Bilgi University · Five students
01 / PROJECT OVERVIEW
A compact sensing, decision, and motion loop.
The project focused on validating directional light tracking at prototype scale. It was not designed as a commercial installation or a long-term energy-yield study.
- PROBLEM
- A fixed panel cannot respond to changes in incoming light direction.
- APPROACH
- Compare relative light intensity from four directions and update two servo angles.
- INPUTS
- Four analog LDR readings.
- CONTROLLER
- Arduino Uno.
- OUTPUTS
- Horizontal and vertical servo movement.
- STATUS
- Functional academic prototype.
02 / SYSTEM ARCHITECTURE
Relative light becomes coordinated panel movement.
Each stage has one job: sense the imbalance, reduce it to two directional errors, decide whether movement is necessary, and command the relevant axis.
01LIGHT FIELD
Top-right illumination creates an unequal field.
024 READINGS
ILLUSTRATIVE VALUES
03DIRECTIONAL GROUPING
TOP = avg(TL, TR) 75
BOTTOM = avg(BL, BR) 49
LEFT = avg(TL, BL) 47
RIGHT = avg(TR, BR) 77
042 ERRORS
VERTICAL
75 - 49 = +26
TOP STRONGER
HORIZONTAL
47 - 77 = -30
RIGHT STRONGER
05TOLERANCE
OUTSIDE
UPDATE AXIS
INSIDE
HOLD
Each error is checked independently.
06ACTUATION
H SERVO
ROTATE RIGHT
V SERVO
TILT UP
07PHYSICAL RESULT
Azimuth and tilt combine into one orientation.
03 / INTERACTIVE SENSOR LOGIC
Four readings resolve into two errors.
Move the light source to see each quadrant reading flow through directional averages, error checks, servo commands, and panel movement.
topAverage = average(TL, TR)bottomAverage = average(BL, BR)leftAverage = average(TL, BL)rightAverage = average(TR, BR)verticalError = topAverage - bottomAveragehorizontalError = leftAverage - rightAverageINTERACTIVE SENSOR LAB
Drag or tap the light. Keyboard: arrow keys to move, Home to center.
01 / SENSOR FIELD
STRONGEST · TR02 / CALCULATION BRIDGE
Four readings become four directional averages, then two signed errors.
HORIZONTAL ERROR
VERTICAL ERROR
MECHANICAL RESPONSE
TWO AXES / ONE ORIENTATIONHORIZONTAL COMMAND
ROTATE RIGHT
VERTICAL COMMAND
TILT UP
HORIZONTAL SERVO
106°
AZIMUTH RIGHT
VERTICAL SERVO
102°
TILT UP
Illustrative angles show the commanded direction. Original calibrated ranges are not documented.
Values, tolerance, and angles are simulated for explanation; they are not historical prototype measurements.
04 / TOLERANCE AND STABILITY
Not every difference should cause movement.
LDR channels can differ slightly because of electrical noise, sensor mismatch, shadows, or small changes in the light field. Reacting to every variation would keep the mechanism in motion.
A tolerance, also called a deadband, creates a stable region around balance. Inside it, the controller holds position. Outside it, only the relevant servo axis is updated.
The practical result is less oscillation, fewer unnecessary corrections, and reduced servo jitter.
ILLUSTRATIVE DEADBAND BEHAVIOR
Two independent decisions in the same loop
HORIZONTAL ERROR = LEFT - RIGHT
COMMAND · ROTATE RIGHT
VERTICAL ERROR = TOP - BOTTOM
COMMAND · HOLD
05 / HARDWARE CONFIGURATION
Four analog inputs drive two independent actuator outputs.
Each LDR and fixed resistor form a voltage divider. Four divider nodes feed the controller, while separate signal and power relationships support the two servos.
SIMPLIFIED SIGNAL-FLOW SCHEMATIC
TL
TR
BL
BR
ARDUINO UNO / MICROCONTROLLER
Four generic analog inputs · Two servo signal outputs
SIGNAL H
Horizontal servo
SIGNAL V
Vertical servo
EXTERNAL ACTUATOR POWER
Separate power paths feed both servos; signal paths remain distinct.
06 / CONTROL LOGIC
A short loop connects sensing to constrained motion.
Simplified logic for one pass through the repeating embedded control cycle.
REPEATING CONTROL CYCLE
INSIDE
HOLD
OUTSIDE
UPDATE AXIS → CLAMP
read TL, TR, BL, BR
top = average(TL, TR)
bottom = average(BL, BR)
left = average(TL, BL)
right = average(TR, BR)
verticalError = top - bottom
horizontalError = left - right
if abs(verticalError) > tolerance:
update vertical angle
if abs(horizontalError) > tolerance:
update horizontal angle
clamp angles to mechanical limits
write angles to servosAngle commands are clamped before the values are written to the servos.
07 / ENGINEERING DECISIONS
The important work happened between the readings and the motion.
The hardware was simple. Stable behavior depended on how those components were interpreted and constrained.
- 01
Four sensors establish direction
Four quadrants provide left-right and top-bottom comparisons that a single brightness reading cannot.
- 02
Averages reduce four readings to two errors
Directional pairs collapse four sensor values into one horizontal and one vertical control signal.
- 03
Deadband prevents unstable corrections
A central hold region stops small analog differences from repeatedly reversing a servo command.
- 04
Mechanical limits constrain valid commands
Clamping keeps mathematically valid angle updates inside the mechanism's usable movement range.
08 / OUTCOME
The sensing and control concept worked at prototype scale.
The prototype demonstrated that relative light intensity from four analog sensors could be converted into coordinated horizontal and vertical motion.
It behaved as a directional light-tracking prototype, not as a production-ready solar installation. The work validated the sensing-to-motion loop rather than long-term energy performance.
DOCUMENTED BOUNDARY / LIMITATIONS
What the prototype did not establish.
- No calibrated energy-yield comparison
- No long-term outdoor testing
- No weather-resistant enclosure
- No data logging
- No independent panel-angle feedback
- Dependence on ambient light conditions
- Sensitivity to sensor mismatch
- Prototype-scale mechanical construction
09 / FUTURE IMPROVEMENTS
Turn a responsive prototype into a measurable system.
These are realistic next steps, not features completed in the June 2024 prototype.
01SIGNAL QUALITY
- Sensor calibration
- Moving-average filtering
- Hysteresis
- Sensor matching checks
02POWER AND MECHANICS
- Separate regulated servo power
- Limit switches
- Improved structure
- Weather protection
03VALIDATION AND CONTROL
- Current and voltage sensing
- Energy-yield logging
- Fixed-panel comparison
- Outdoor validation
- Proportional or PID movement
- Hybrid sensor and astronomical tracking
A stronger future version could combine calibrated sensor feedback with a predicted sun position. That hybrid approach would retain local correction while providing a reference when the light field is diffuse.
10 / CONCLUSION
Simple parts can form a responsive physical system when the control boundaries are clear.
The project showed how analog sensors, a microcontroller, and constrained actuator logic can connect sensing, decision-making, and motion. Its main value was demonstrating the complete path from analog sensing to physical motion.
